选型指南
TFT LCD Controller
Item Resolution?
(Max)
Color MCU I/F Panel Media Decoder 2D Engine Alpha blending PIP
RA8889
1366x768

16.7M

8/16bit parallel
3/4 Wire SPI ,IIC

CMOS/TTL

Motion JPEG

Yes

Yes

Yes
Item Resolution?
(Max)
Color MCU I/F Panel Ext .SDRAM 2D Engine Alpha blending PIP
RA8889 480x320
320x480
16.7M 8/16bit parallel
3/4 Wire SPI ,IIC
CMOS/TTL - Yes Yes Yes
TFT LCD Controller
Item Resolution?
(Max)
Color MCU I/F Panel Ext .SDRAM 2D Engine Alpha blending PIP
RA8871M 480x320
320x480
16.7M 8/16bit parallel
3/4 Wire SPI ,IIC
CMOS/TTL - Yes Yes Yes
RA8873M 800x480
480x800
65K 8/16bit parallel
3/4 Wire SPI ,IIC
CMOS/TTL - Yes Yes Yes
RA8876 1366x768 16.7M 8/16bit parallel
3/4 Wire SPI ,IIC
CMOS/TTL 16Mb-512Mb Yes Yes Yes
RA8876M 1366x768 16.7M 8/16bit parallel
3/4 Wire SPI ,IIC
CMOS/TTL - Yes Yes Yes
RA8877 1366x768 16.7M 8/16bit parallel
3/4 Wire SPI ,IIC
LVDS 16Mb-512Mb Yes Yes Yes
Item Resolution?
(Max)
Color MCU I/F Panel Ext .SDRAM 2D Engine Alpha blending PIP
RA8871M 480x320
320x480
16.7M 8/16bit parallel
3/4 Wire SPI ,IIC
CMOS/TTL - Yes Yes Yes
RA8873M 800x480
480x800
65K 8/16bit parallel
3/4 Wire SPI ,IIC
CMOS/TTL - Yes Yes Yes
RA8876 1366x768 16.7M 8/16bit parallel
3/4 Wire SPI ,IIC
CMOS/TTL 16Mb-512Mb Yes Yes Yes
RA8877 1366x768 16.7M 8/16bit parallel
3/4 Wire SPI ,IIC
LVDS 16Mb-512Mb Yes Yes Yes

TFT LCD Controller
Item Resolution?
(Max)
Color SPI I/F Panel Touch Controller 2D Engine
+ BTE
Ext Font?
ROM I/F
DMA
RA8870 640X480 256/4K/65K - Digital/
Analog
4/5 wires
(R-Type)
Yes Yes
(Parallel)
-
RA8872 320X240 256/4K/65K - Digital 4 wires
(R-Type)
Yes Yes -
RA8875 800X480 256/65K 3/4 CMOS/TTL 4 wires
(R-Type)
Yes Yes
(Serial)
Yes
Item Resolution?
(Max)
Color SPI I/F Panel Touch Controller 2D Engine
+ BTE
Ext Font
ROM I/F
DMA
RA8870 640X480 256/4K/65K - Digital/
Analog
4/5 wires
(R-Type)
Yes Yes
(Parallel)
-
RA8872 320X240 256/4K/65K - Digital 4 wires
(R-Type)
Yes Yes -
RA8875 800X480 256/65K 3/4 CMOS/TTL 4 wires
(R-Type)
Yes Yes
(Serial)
Yes
